Mode No. AD588
Rated Voltage ：DC 22.2
Power rating ：2*60W
Output ：11000lumens+
Battery capacity ： 25 Ah
Materials ：ABS, yellow finish
Dimming ： 25%~100% Stepless Dimming
Runtime at full power ：6hrs
Runtime at spot light on ：12 hrs
Runtime at flood light on ：20 hrs
Charging time ：No more than 8hrs
Lifespan ：20000 hrs
IP rating ： IP66-light head / IP54- case
Dimension : 56.7*32.5*23cm
Dimension when head lift : 190*32.5*23cm
Net. Weight : 19.0 kg
Rotable angle : 360° H & 90 ° V
Indicator : Yes, red and blue flash
In the Kit : Light / USB cable / Nylon belt / AC 220V Charger-Scuko socket / 12V Car charger
Features
-The unique lamp head design allows for concentrated light for long-distance illumination, or easily converts to floodlight for large-area illumination.
-A switchable blue and red warning light on the back of the lamp head effectively alerts passing vehicles, protects workers, and meets the lighting needs of various locations.
-The lamp head can rotate 360° horizontally and 90° vertically to adjust the illumination direction.
-The lamp head is fixed with a four-section lifting rod with a maximum lifting height of 1.5 meters
-LCD screen, to display the different lighting mode, battery life and remaining lighting time.
-Can be used as a power bank to charge other devices
-Dimming function, stop at any brightness desired, e.g. 25% brightness, about 16hrs runtime
-More than 500 times charge cycles
Precautions:
1. The lamp must be placed on a flat surface during use to prevent it from tipping over.
. The metal surface of the lamp holder can be very hot during normal use. Be careful to avoid burns when adjusting the lamp.
3. To ensure long-term operation, please regularly check and adjust the lift rod locking mechanism.
4. If you need to move the lamp while in use, the lift rod must be lowered into position before moving.
Instructions:
-For first-time use, open the box lid, remove the sensor light from the plastic bag, and install it on the sensor light bracket on the lid.
-To use the lamp, place the box upright and open the lid. First, remove the lamp head lift rod. Attach the lamp head lift rod to the adapter tube and secure the clip. Then, remove the lamp head and attach it to the lift rod. Place the slingshot line on the hook, connect the lamp head connectors, and then connect them to the box's lamp head connector. This completes on-site.
